- 6 Feeder Pockets
- Cover Feeder
- 2 Stitching heads
- 3 knife Trimmer
- Bindery Compensating Stacker (RIMA RS-10S)
Key Specifications
- Maximum Untrimmed Size (Manual Feed): 355 x 311 mm
- Maximum Trimmed Size with Lap: 349 x 305 mm
- Minimum Trimmed Size (Standard): 89 x 120 mm
- Maximum Product Thickness: 10 mm
- Maximum Stitching Thickness: 5 mm
- Maximum Pile Height at Feeder: 205 mm
- Production Speed: 1,500 to 9,000 cycles per hour
Configuration and Features
- Feeders: Typically equipped with 6 automatic feeders
- Cover Feeder: 1 unit
- Stitching Unit: 2 stitching heads
- Trimmer: Three-knife trimmer for precise finishing
- Delivery System: Rima RS-10 – Compensating Bindery Stacker with 13″ drop
